TWIST12 HRF4

Straight Twist Slip-clutch Screwdriver is equipped with a spring-operated slip clutch that applies a pulsating force when the torque level is reached

Katalog
Ringkasan

Kenapa TWIST12 HRF4

Straight Twist Slip-clutch Screwdriver is equipped with a spring-operated slip clutch that applies a pulsating force when the torque level is reached. These tools are suitable where the torque level may temporarily rise during the rundown phase, for instance when using sheet metal screws, wood screws or self-tapping screws.

Katalog TWIST12 HRF4PDF resmi dari ATLAS COPCO Butuh saran atau harga?Tim penjualan kami membalas dalam 1 hari kerja

Spesifikasi Teknis

Specification

CategorySpecification
Certifications

• EAC Certified: Yes

• EU Compliance: 2006/42/EC

• UK Regulations: S.I. 2008/1597

Standards

• ISO 11148-6 (EU/UK)

• Sound: ISO 15744

• Vibration: ISO 28927-2

Performance

• Free Speed: 850 rpm

• Torque Range: 0.37-3.25 ft-lb (4.4-38.9 in-lb)

Design Features

• Model: Balanced Pistol (Multiple Air-Inlet)

• Drive: Slip-clutch

• Output: 1/4" Female Hex

• Start: Dual Trigger/Push

• Shut-off: Slip-clutch

Air System

• Consumption: 2.8 CFM

• Max Pressure: 100 psi

• Inlet: 1/8" NPT

• Hose: 6mm

Dimensions & Weight

• Length: 200mm (7.87")

• CS Distance: 15mm (0.59")

• Weight: 1.5 lb (0.68 kg)

Noise/Vibration

• Sound: 80 dB(A) ±3dB

• Vibration: <2.5 m/s²

Identification• SCIP: 246d0aa9-e82e-44b8-8427-2cd21c43a003
