ENDO KOGYO Air Hoist Ada
Type ATC - Rated load between 60 and 125 kg
## Chain type This type of Air Hoist is equipped with a surface-hardened load chain that is made of alloy steel and has excellent toughness and wear resistance
Ringkasan
Kenapa Type ATC - Rated load be...
## Chain type This type of Air Hoist is equipped with a surface-hardened load chain that is made of alloy steel and has excellent toughness and wear resistance. The up and down buttons and handle are mounted on the lower hook. While ensuring the stability of a suspended load, this type of Air Hoist provides better controllability compared to the pendant type.
Katalog Type ATC - Rated load betwee...PDF resmi dari ENDO KOGYO
Butuh saran atau harga?Tim penjualan kami membalas dalam 1 hari kerja
Spesifikasi Teknis
| Model | Rated load (kg) | Stroke (m) | Air pressure Mpa(kgf/c㎡) | Lifting speed (m/min) | Air consumption (m³/min) | Chain (size x fall) | Air inlet | Mass (kg) | Emergency stop button |
|---|---|---|---|---|---|---|---|---|---|
| ATC-60K | 60 | 2 | 0.4(4) | 14.0 | 0.45 | 4.0×1 | Rc 3/8 | 14.3 | － |
| 0.5(5) | 17.5 | 0.58 | |||||||
| 0.6(6) | 20.0 | 0.68 | |||||||
| ATC-60K-5 | 60 | 2 | 0.4(4) | 14.0 | 0.45 | 4.0×1 | Rc 3/8 | 14.3 | 〇 |
| 0.5(5) | 17.5 | 0.58 | |||||||
| 0.6(6) | 20.0 | 0.68 | |||||||
| ATC-125K | 125 | 2 | 0.4(4) | 6.5 | 0.42 | 4.0×1 | Rc 3/8 | 14.5 | － |
| 0.5(5) | 10.5 | 0.55 | |||||||
| 0.6(6) | 12.0 | 0.65 | |||||||
| ATC-125K-5 | 125 | 2 | 0.4(4) | 6.5 | 0.42 | 4.0×1 | Rc 3/8 | 14.5 | 〇 |
| 0.5(5) | 10.5 | 0.55 | |||||||
| 0.6(6) | 12.0 | 0.65 |
